PQ96230

Highly Integrated Wireless Receiver

PQ96230PQ96230

PQ96230

PQ96230 30W Highly Integrated Wireless Receiver

The PQ96230 is a highly-integrated wireless power receiver/transmitter. In RX mode, it supports up to 30W power, 10V/3A. In TX mode, it supports 10W power out. The PQ96230 integrates a synchronous full-bridge rectifier, a low-dropout main LDO, 5 channels 12-bit ADC, ASK modulate & FSK demodulate module, internal LDOs, Vrect UVP/OVP, main LDO OCP/OTP/SCP protection function, I2C. The device is available in an ultra-small WLCSP-40 2.298mm x 3.258mm package.
PQ96230
The PQ96230 is a highly-integrated wireless power receiver/transmitter. In RX mode, it supports up to 30W power, 10V/3A. In TX mode, it supports 10W power out. The PQ96230 integrates a synchronous full-bridge rectifier, a low-dropout main LDO, 5 channels 12-bit ADC, ASK modulate & FSK demodulate module, internal LDOs, Vrect UVP/OVP, main LDO OCP/OTP/SCP protection function, I2C. The device is available in an ultra-small WLCSP-40 2.298mm x 3.258mm package.
Product Details
Design / Development
Technical Documentation
Applications

Product Details

Technical Documentation

Applications

Smart terminals such as mobile have become an integral part of life. Users have higher requirements for the performance, range, and quality of their devices.
2025.02.16
Learn more
Parameter NameParameter Value
Pout_Max30W
ProtocolQI2.0/MPP
Vrect range4.5V ~ 13V
Vout range4.5V ~ 12V
Abs. Vrect (max)20V
SR Rdson4* 30mΩ
Parameter NameParameter Value
MLDO Rdson30mΩ
MTP32kB
ADC resolution12bit
IQ5mA
PackageWLCSP-54 2.298mm x 3.258mm
TX mode√
Parameter NameParameter Value
Pout_Max30W
ProtocolQI2.0/MPP
Vrect range4.5V ~ 13V
Vout range4.5V ~ 12V
Abs. Vrect (max)20V
SR Rdson4* 30mΩ
MLDO Rdson30mΩ
MTP32kB
ADC resolution12bit
IQ5mA
PackageWLCSP-54 2.298mm x 3.258mm
TX mode√
