PQ7061A

The PQ7061A is a highly integrated, single-cell, Li-ion/Li polymer battery charger with system power path management and I2C interface for space-limited portable applications.The PQ7061A takes input power from either an AC adapter or a USB port to supply the system load and charge the battery simultaneously. The PQ7061A providethe charge management functions including trickle charge, constant current charge, constant voltage charge, charge termination and auto-recharge. The power path management function ensures continuous power to the system by automatically selecting the input, battery, or both to power the system. This function features alow drop out regulator from the input to the system and a 70mΩ switch from the battery to the system. Power path management separates the charging current from the system load, which allows for proper charge termination and keeps the battery in full-charge mode. The PQ7061A provides a system short-circuit protection (SCP) function by limiting the current from the input to the system and the battery to the system. This feature is especially critical for preventing the Li-ion battery from being damaged due to an excessively high current. Anon chip battery under-voltage lockout (UVLO) cuts off the path between the battery and th esystem if the battery voltage drops below a programmable battery UVLO threshold. This prevents the Li-ion battery from being over-discharged. An integrated I2C control interface allows the PQ7061A to program the charging parameters, such as input current limit, input minimum voltage regulation, charging current, battery regulation voltage, safety timer, and battery UVLO.
